JS14S-2 AC/DC 100-240V 99min on-delay DPDT time Relay JS14S Series 100-240VAC/100-240VDC 220V 110V delay Timer

Turn Signal RelaysJS14S digital time relayfinglaiContact form and delay timeModel number Contact form Delay time Related product JS14S-2 On-delay DPDT 9.9s/99s/99m/99h/0.1s-99h Visiting... JS14S-3 On-delay DPDT 9.99s/99.9s/999s/999m/999h/1s-9m59s/1m-9h59m/0.01s-999h Order JS14S-4 On-delay DPDT 99.99s/999.9s/9999s/9999m/9999h/1s-99m59s/1m-99h59m Order finglaiJS14S-2 time relay model number legendJS14S-2Parent Model Number-DASupply voltage-DA: 100-240VAC/DC-380VAC: 380VAC-24V: 24VAC/DC-12V: 12VAC/DC-99MDelay time-9.9S: 9.9s-99S: 99s-99M: 99min-MT: 0.1s-99hfinglaiGeneralModel number JS14S Supply voltage 100V-240VAC/DC; 36, 380 Vac, 50/60 Hz; 12, 24 Vdc; Tolerance -15% ... 10% at AC and -10% ... 10% at DC of rated supply voltage Power consumption 3W max Setting method Dial switch Indication method 8-segment digital display External dimensions 126x104x52 mm Perforate dimensions 7710x4610 mm Contact rating 3A@250Vac, 5A@24Vdc Repeat accuracy ±0.3%, ±0.05 sec Setting error ±0.5%, ±0.05 sec Termination 11 pins Mounting Panel Matched socket PF113A Mechanical life 1x106 Electrical life 1x105 Operating temperature -5 to 45 °C (23 to 113 °F) Operating humidity 95% RH max, non-condensing Alias name JS14S digital timer finglaiJS14S-2 time relay related productsNo Model Number Supply Voltage Delay Time Related Product 1 JS14S-2-DA-9.9S 100-240VAC/DC 9.9s Order 2 JS14S-2-DA-99S 100-240VAC/DC 99s Order 3 JS14S-2-DA-99M 100-240VAC/DC 99min Visiting... 4 JS14S-2-DA-MT 100-240VAC/DC 0.1s-99h Order 5 JS14S-2-380VAC-9.9S 380VAC 9.9s Order 6 JS14S-2-380VAC-99S 380VAC 99s Order 7 JS14S-2-380VAC-99M 380VAC 99min Order 8 JS14S-2-380VAC-MT 380VAC 0.1s-99h Order 9 JS14S-2-24V-9.9S 24VAC/DC 9.9s Order 10 JS14S-2-24V-99S 24VAC/DC 99s O
